Brackish Water Desalination System for Agriculture
Production capacities from 550 to 5,000 liter/hour (2.4-22 USgpm) which adapt better to individual farmer requirements
and to the existing micro-irrigation structures. System characteristics: Optimized energy consumption: using high-efficiency pumps working with Various Speed Diverter (VFD), and low-pressure membranes. Compact design: with powder coating frames. Simple control: One button ON/OFF.
Extensice applications
- Horticulture (e.g. grapes, strawberries, exotic flowers, and temperate vegetables)
- Salt-tolerant crops (e.g. olives, date palm, sugar beets, rapeseed, guar, camelina)
- Plant nurseries
- Individual gardens
Specification:
Feed water standards
Salinity(TDS)^(1))
20,000-5,000mg/L
Temperature
5-35°C
Turbidity^(1))
< 20NTU
Chemical Oxygen Demand (COD)
<10mg/L
Ferrous (Fe^(2)+ )
<0.1mg/L
Manganese (Mn(2)+ )
<0.1mg/L
Oil and grease
<0mg/L
Product water standards
Salinity (TDS)
<400mg/L
pH
6-8
Turbidity
<0.2NTU
Notes:
1) if feed water turbidity is higher than the above specifications, extra prestreatsment might be needed.
2) if the seawater is free of harmful contaminants such as nitrate or fluoride ion, the produced drinking water meets the WHO Guidelines for Drinking Water quality, 4^(th) edition, 2012.
| Feed water standards | ||
|---|---|---|
| Salinity(TDS)^(1)) | 20,000-5,000mg/L | |
| Temperature | 5-35°C | |
| Turbidity^(1)) | < 20NTU | |
| Chemical Oxygen Demand (COD) | <10mg/L | |
| Ferrous (Fe^(2)+ ) | <0.1mg/L | |
| Manganese (Mn(2)+ ) | <0.1mg/L | |
| Oil and grease | <0mg/L | |
| Product water standards | ||
| Salinity (TDS) | <400mg/L | |
| pH | 6-8 | |
| Turbidity | <0.2NTU | |
| Notes: 1) if feed water turbidity is higher than the above specifications, extra prestreatsment might be needed. 2) if the seawater is free of harmful contaminants such as nitrate or fluoride ion, the produced drinking water meets the WHO Guidelines for Drinking Water quality, 4^(th) edition, 2012. | ||
Techncal Data
Unit
AGR0500
AGR01000
AGR03500
AGR5000
Rated Product Flow
L/H
550
1,100
3,500
5000
Rated Recovery Rate
%
60
60
60
60
Rated Feed Flow
M3/H
0.92
1.83
5.83
8.33
Max System Pressure
barg
20
20
20
20
RO Membrane Spec.
inch
4,040
4,040
8,040
8,040
RO Membrane Qty.
pcs
3
6
4
6
Weight(dry)
kg
150
180
350
420
Rated Power
kW
1.81
2.32
7.11
7.45
Energy Consumption
KWh/M3
2.88
2.8
2.73
2.71
Installed Power
kW
2.75
2.75
6.6
7.0
Input
1PH, 220 AC±10%, 50Hz
3PH, 380 AC±10%, 50Hz
| Techncal Data | Unit | AGR0500 | AGR01000 | AGR03500 | AGR5000 |
|---|---|---|---|---|---|
| Rated Product Flow | L/H | 550 | 1,100 | 3,500 | 5000 |
| Rated Recovery Rate | % | 60 | 60 | 60 | 60 |
| Rated Feed Flow | M3/H | 0.92 | 1.83 | 5.83 | 8.33 |
| Max System Pressure | barg | 20 | 20 | 20 | 20 |
| RO Membrane Spec. | inch | 4,040 | 4,040 | 8,040 | 8,040 |
| RO Membrane Qty. | pcs | 3 | 6 | 4 | 6 |
| Weight(dry) | kg | 150 | 180 | 350 | 420 |
| Rated Power | kW | 1.81 | 2.32 | 7.11 | 7.45 |
| Energy Consumption | KWh/M3 | 2.88 | 2.8 | 2.73 | 2.71 |
| Installed Power | kW | 2.75 | 2.75 | 6.6 | 7.0 |
| Input | 1PH, 220 AC±10%, 50Hz | 3PH, 380 AC±10%, 50Hz | |||
